professional series
Nylon PA12 + Carbon
Quantity: 1000g
Empty weight coil: 250g
Diameter of the spool: ca.20cm - Width: ca.6,5cm - Inner diameter hub: ca.5,5cm
Density in g/cm3: 1,03
Diameter: 1,75mm +/- 0,04mm
Roundness: +/-3
Carbon: 15%
Pressure temperature: 270-290 °C
Bed temperature: 70-100 °C
Kexcelled Nylon PA12 + Carbon is a
PA12-based carbon fiber reinforced nylon material with low water absorption and a significant increase in strength, stiffness and heat deflection temperature. This high-performance material can be printed using a commercial printer with a heating platform. It is suitable for lightweight parts that are oil and wear resistant or require high strength. It is recommended to use printing nozzles with diameter over 0.6 mm made of wear resistant materials.
We recommend the use of hardened steel or ruby nozzles with a diameter of 0.5 mm or 0.6 mm.
Properties
Reinforced with carbon fiber
High tensile strength
High stiffness
Dimensional stability
High thermal resistance
High chemical resistance
Low shrinkage and distortion = excellent dimensional stability
Possibility to print with an open printer
To compensate for unevenness on the print bed, the first layer should be printed with a thickness of 0.3mm. The fan should be set to 0 if possible.
A closed installation space and good ventilation is recommended!
