KiS-3d magnetic precision casting plate 256x256mm for BambuLab printer P1P/P1S/X1/X1C.

Simplest handling. No assembly required. The casting plate is simply placed on the already existing magnetic foil.
Due to the integrated magnets, temperature resistant up to 150°/302 °F, it adheres securely to the heating bed.
The spring steel printing surface, whether PEI, PET or even the technical printing plate, is then placed on the magnetic cast plate.

Precision cast plate 256x256x5mm
fine milled, roughness Ra 0,3µm
with circumferential chamfer 0,6mm


24V diaphragm pump for "Berd-Air" system

GL-8H - Proximity Sensor Inductive
Compact inductive proximity sensor with LED display
Cable length: 100cm

PLA Carbon Filament, vacuum packed

Quantity: 1000g
Empty weight spool: 300g
Diameter of spool: ca.20cm - Width: ca.7cm - Inner diameter hub: ca.5cm
Total: 1500g

Density in g/cm3: 1,22
Diameter: 1,75mm +/- 0,02mm
Roundness: +/-3
Carbon fibre 10%
Pressure temperature: 200-230 °C
Bed temperature: (optional) 40-65 °C

Good optical properties
High surface hardness
Flexural strength 112 MPa
Low flammability
High UV resistance
Dimensional stability is about 64 degrees
For direct drive and Bowden extruders


PAHT K7CFLM 500gr

Quantity: 500g
Empty weight coil: 250g
Diameter of the spool: ca.20cm - Width: ca.6,5cm - Inner diameter hub: ca.5,5cm

Total: 800g

Density in g/cm3: 1,03
Diameter: 1,75mm +/- 0,04mm
Roundness: +/-3

Carbon: 15%

Pressure temperature: 270-290 °C
Bed temperature: 70-100 °C

PAHT K7CFLM is a PA12-based carbon fiber reinforced nylon material with low water absorption and a significant increase in strength, stiffness and heat deflection temperature. This high-performance material can be printed using a commercial printer with a heating platform. It is suitable for lightweight parts that are oil and wear resistant or require high strength. It is recommended to use printing nozzles with diameter over 0.6 mm made of wear resistant materials.
High mechanical performance High strength and stiffness Carbon fiber reinforced.

We recommend the use of hardened steel or ruby nozzles with a diameter of 0.5 mm or 0.6 mm.

Properties

Reinforced with carbon fiber
High tensile strength
High stiffness
Dimensional stability
High thermal resistance
High chemical resistance
Low shrinkage and distortion = excellent dimensional stability
Possibility to print with an open printer

To compensate for unevenness on the print bed, the first layer should be printed with a thickness of 0.3mm. The fan should be set to 0 if possible.
A closed installation space and good ventilation is recommended!



High quality silicone heating mat

for e.g. RatRig 400 and others
with hole for screw-in thermistor

380x380mm 230V 1000W

with temperature sensor NTC 100 / 3950
cable length 200cm
temperature resistant adhesive foil 3M 467MP
incl. JST connector set for thermistor

Sensor type in Marlin :
30 : Kis3d Silicone NTC100K / B3950 (4.7k pullup)

Axial fan  by ADDA 40x40x10mm 24 Volt

Extra class quality, extremely quiet running and at the same time very good performance speak for this fan.

Height 40mm
Width 40mm
Depth 10mm
Operating voltage: 24V DC
Air flow : 9,9 m³/h
Speed : 4400 rpm
Loudness : 22 dB
Cable length: 30cm
incl. JST plug set
